Zero 88 FLX S24 2U Universe 2 Lighting Desk

Description

The FLX S 24 is easy to learn and simple to use - delivering all the features you need at an affordable price. It is flexible, offering a powerful LED and moving light controller in a small 19” unit with direct access to each of the lights in your rig.

Quickly and accurately control colour changing lights using the multi-touch colour & image picker, the encoder wheels or by selecting colours contained within a“mood” using Mood Boards by Lee Filters, and quickly record it straight onto any fader or one of the 48 instant-access colour palettes to recall later. Moving lights can be controlled using the multi-touch pan/tilt grid, the encoder wheels or with automatic effects like “Figure 8”, “Rainbow” and “Fly-In”.

From design to manufacture, the FLX S24 has been developed to work in a wide range of applications, with specific considerations for education, houses of worship, fringe theatre, community venues, corporate events, concerts, rental, fashion, festivals, holiday parks, cruise ships, TV and many more...

Built in tools such as Patch Wizard and Auto Palettes do all the prep work, getting you ready to operate quicker than ever before. Programming time is reduced with a simple three-step programming method for moving lights, colour changing and conventionals - what you want, how you want it, where you want it. And for all those really important features you need over and over again – you always have direct instant access via the dedicated Z button.

Control up to 48 LED, moving lights and conventionals
24 multi-function faders
49 playbacks (each with submaster & full cuestack functionality)
48 groups, 4 x 48 palettes (Colour, Beamshape, Position, Effect)
19" rackmountable (6 rack units high)
Multi-touch interfaces for Colour and Moving Lights
Dedicated GO button & playback fader for theatrical control
Hands-on intuitive control via 4 encoder wheels
Free mobile apps for wireless control of your ZerOS console on iOS and Android devices
Multi-lingual step-by-step touch screen guidance
Art-Net 4 and sACN for network output & wireless connection to smart phone / remote monitors
7” multi-touch screen
Automatic Groups, Palettes, Effects and Macros
Colour picking, mixing & image capture
Mood Boards by LEE Filters
Additive, subtractive and HSV control
Store single or mulitple cues on each of the playbacks
Built-in fixture library
RDM compatability
Showfile compatability with other ZerOS consoles
Quiet, dust free, fanless operation
Two DMX universes
Two XLR Outputs (1 x 5 pin + 1 x 3 pin)
3 year warranty

Hardware - Front Panel
24 Multifunctional Faders (channels or playbacks, with select or go buttons)
Internal 7” multi-touch screen
Master Playback with Go Button playback and master intensity
4 embedded encoder wheels with select buttons
Dedicated buttons for key functions
Hardware - Inputs/Outputs
1 5-pin XLR connector for DMX and RDM
1 3-pin XLR connector for DMX and RDM
Ethernet (visualisation and Remote Apps)
2 Universes over Ethernet using Art-Net 4 or sACN
2 multipurpose USB ports (saving shows, connection of accessories & Wings, software updates)
External power supply
Software - capacity
48 Fixture Controls (using single or multiple DMX channels)
49 Playbacks (equivalent of Cue Stacks, Submasters or Chases)
10,000 cues
4 x 48 Palettes (Colour, Beamshape, Position, Effect)
48 groups
Software - features
Integrated colour picker and “Mood Boards by LEE Filters”
Multi touch Pan/Tilt grid
Auto palettes, groups and fixture macros
Gobo previews and library
Move on Dark
Tracking and Non-Tracking modes available
Support for wireless remote control through handheld devices and remote monitors
Electrical
Supply voltage range: 100 - 240V AC; MAX 2A
Frequency: 50 - 60Hz
Operating temperature: +5 to +40°C
Physical & Dimensions
Height: 68mm
Width: 461mm
Depth: 284mm
Weight: 4kg
