Proel MQ12USB 12-input 4-bus Mixer With Effect and USB

Description:

MQ is a series of mixers created by PROEL to offer in a very compact and stylish package a high input density, a full set of features and a superior audio quality, at a very convenient price point. The MQ series includes 5 models with 6, 10, 12 and 16 inputs, able to satisfy most of the sound reinforcement applications. Carefully designed and engineered in Italy by PROEL R&D, MQ mixers are hosted in ultra-rugged cases, providing extended durability for a stage-proof use.

The smallest models of the series, MQ6 and MQ6FX, offer in an ultra-compact format the performance of professional consoles, delivering a clean and accurate sound. The MQ6FX, despite its small size, includes a high-quality 24-bit DSP able to provide musicians and performers with studio-grade effects.

MQ10FX, together with 3-band EQ and one-knob intelligent COMPRESSORS, offers also 100 DSP presets with a convenient LED display for the selection.

MQ12USB additional features include an USB audio I/O interface and extended mixing capability with MONITOR send, STEREO GROUP bus and 45mm control faders.

The top-of-the-line MQ16USB feature 16 inputs and 12 microphone channels together with sweep mids and one-knob intelligent COMPRESSORS on mono channels, 4 AUX sends, STEREO GROUP bus and 60mm control faders.

Optional padded carrying bags and metal brackets for 19” rack mounting are available for selected models.

Compact 12-input 4-bus mixer with effect and USB I/F
4 MONO MIC/LINE inputs, 2 STEREO MIC/LINE inputs and 2 STEREO LINE inputs
6 low-noise, very high-headroom microphone preamplifiers
PHANTOM power
‘One-knob’ COMPRESSOR with LED indicator on MONO channels
3-band EQ with sweep mids and LO-CUT filter
1 AUX send pre-fader and 1 AUX send post-fader
24bit studio-grade digital effect with 100 presets, 2-digit display and footswitch MUTE
Built-in USB interface for PC recording and playback
GROUS 1&2 with MIX routing and output
HEADPHONES and CONTROL ROOM outputs
Electronically balanced MAIN MIX outputs with XLR-M and ¼” JACK connectors
Two 8-LED VU-METERS
Universal switching power supply 100-250V
Stage-proof construction and ultra-rugged metal chassis
Designed and engineered in Italy by PROEL

Specifications:

MONO INPUT CHANNEL
Mic Input
sensitivity
from -10 to -50 dB
Balanced XLR-F

impedance
2 Kohm

Line Input
sensitivity
from +20 to -20 dB
Balanced JACK

impedance
10 Kohm

Lo cut

75Hz, 18dB/oct.

EQ
HIGH (shelving)
±15 dB @ 12 KHz


MID (peaking)
±15 dB @ 2.5 KHz


LOW (shelving)
±15 dB @ 80 Hz

Compressor
Fet
CH 1-4, 1-knob

STEREO INPUT CHANNEL
Mic Input
sensitivity
from -10 to -50 dB
Balanced XLR-F

impedance
2 Kohm

Line Input
sensitivity
from +20 to -20 dB
Balanced JACK

impedance
10 Kohm

Line Input
sensitivity
-10 dB
Balanced JACK, RCA

impedance
10 Kohm

EQ
HIGH (shelving)
±15 dB @ 12 KHz


MID (peaking)
±15 dB @ 2.5 KHz


LOW (shelving)
±15 dB @ 80 Hz

MASTER SECTION
MAIN MIX
nom. out level
 +4 dBu
Balanced JACK and XLR-M
C. ROOM output
nom. out level
0 dBu
Unbalanced JACK
GROUP output
nom. out level
 +4 dBu
Balanced JACK
FX/AUX output
nom. out level
0 dBu
Unbalanced JACK
HEADPHONES
min. impedance
32 ohm


max. out level
(2x) 193 mW
Stereo JACK
USB

Stereo IN/OUT, 16-bit converter, 48 KHz sample rate
Type B
DIGITAL EFFECT PROCESSOR
Effects

100 presets

A/D and D/A converters

24 bit

DSP resolution

24 bit

Controls

2-DIGIT display, DIAL, PEAK LED, MUTE switch, MUTE footswitch

GENERAL SPECIFICATIONS
Maximum level
all outputs
+22 dBu

Crosstalk
meas. at 1 KHz
> 82 dBu

HUM & Noise
unweighted
< -93 dBu

THD + Noise
at +4dB, 1kHz
< 0,008 %

Dimensions (WxHxD)

346 x 355 x 95 mm

Weight

4,50 kg

POWER REQUIREMENTS
Mains Supply Voltage

110-240 VAC (±10%) 50 / 60 Hz available with


Europe mains cord (Shucko plug)


US mains cord (NEMA 5-15P plug)


UK mains cord (BS1363 plug)

Consumption

35 W
