Palmer RMMS 8 8-Channel Mic Splitter

The PRMMS8 is an ultra low noise 8-channel microphone splitter providing a direct output and a transformer isolated output for each balanced XLR input. For extra flexibility, four front panel switches enable channel linking which permits routing a single input signal to multiple outputs feeding FOH, monitor, recording and broadcast mixing consoles, or merging two input signals into a single output. For use with condenser microphones, the direct outputs serve as a path for phantom power. Each channel includes a ground lift switch to eliminate hum and interference caused by ground loops between electronic equipment connected to the PRMMS8.

Features
Single space 8-channel rackmount microphone splitter
Transformer isolated and direct outputs
Channel pair link switches for doubling outputs or merging inputs
Individual ground lift on each channel
Suitable for phantom powered condenser microphones and DI boxes

Specifications
Product type: Splitters
Type: mic split
Split type: 1 in 1 +1
Channels: 8
Inputs: 1
Input connectors: XLR
Max. input level: +5 dBu
Number of split-outputs per canal: 1
THRU outputs/channel: 1
Max Output Level: +5 dBu
Output connectors: XLR
Transformer isolated outputs: Yes
Cabinet material: sheet steel
Cabinet surface: Powder coated
Width: 483 mm, 19 "
Depth: 73 mm
Height: 44.5 mm, 1 U
Weight: 1,3 kg
