NewHank Workmate MK2

Description
WORKMATE MK2 version has no crossfader section and pan control but offers 3 adjustable stereo outputs instead.This is a great feature for it allows you to distribute the same stereo output signal to 3 different stereo zones. 4 volume/channel faders and the possibility of connecting 9 external devices, including 2 record players. Switching between these devices is easily done thru Select Switches on the front.

Features
Compact 2u low noise audio design
4 line control channels plus separate Mic section
2 stereo phono, 7 stereo Line and 3 Mic inputs
2-band equaliser per channel
CUE per channel plus gain control
3 independent adjustable stereo outputs
Stereo Master audio out on both RCA and balanced XLR
Balanced stereo Booth output on 6.3MM connectors
Stereo Zone output on RCA connectors
The player section:
Smart Media Player
Select play from USB, SD (both max 32GB) and thru Bluetooth
Plays both WAV and MP3 files
All, Single, Repeat and Random Play


Specification
Power Consumption:12W typical, 21W w/ full headphone output.
Power Supply:Integrated transformer AC 230V-50Hz.
Weight:3 kg
Mic:600 ohm input impedance unbalanced
Line:9V rms max
Dimensions:19\" 2he Rack mount, Front 483x88mm Rear
Line/Aux:10Kohm input impedance
Package Dimension:555 x 325 x 470 mm
Operating Temperature:5 to 35 deg. CC
Humidity:25 to 85%.(Non-condensing)
Storage Temperature:-20 to 60 deg. C
