Cat6 U/UTP LSZH Network Cable 305m Lilac

Vendor: Mercury

SKU: 106-808.015UK

In Stock

Quantity:

I agree with

iFrame

DETAILS
DELIVERY AND RETURNS

Description
Cat6 oxygen free copper twisted pair data cable with low smoke zero halogen sheath. Supplied in dispensing box and marked at 1 metre intervals. This cable is designed for high speed data transmission such as Gigabit Ethernet applications.

Features
Low smoke zero halogen sheath material compliant to RoHS minimises the risk of thick black smoke and poisonous fumes in the event of a fire
Oxygen free solid copper conductor
Supplied in an easy-pull dispensing box
Passes Cat6 fluke test 100m at 250MHz
Complies to TIA/EIA-568 Cat6 standard
HDBaseT Compliant

Specifications
Strands8 x 1/0.54mmØ ±2%
Conductor CSA8 x 0.229mm²
Cable : diameter5.8mmØ
InsulationHDPE 0.195mm thickness
SheathLSHF 0.55mm thickness
Capacitance5.2nF/100m
DC resistance @ 20°C<9.5 ohms/100m
Impedance (1 to 250MHz)100±15 ohms
Return loss>17.3dB @100m
Attenuation<32.8dB @100m
NEXT>38.3dB
PSNEXT>36.3dB
ELFEXT>19.8dB
PSELFEXT>16.8dB
Phase delay<570ns
Cable colourLilac
Length305m
Weight12.7kg
ConductorSolid OFC
