ANTARI DarkFX Strip 1020

The Antari DarkFX Strip 1020 is an efficient high-output and low-power consumption UV LED bar that delivers a peak wavelength of 365 nm and radiant flux output of 9000 mW at full intensity with minimum visible light. This ensures all UV-reactive materials reflect perfectly with stunningly bright and vivid colors. Equipped with 12 x 1.9 W high-power UV LEDs, it features a 40° beam angle, flicker-free operation and special optics to prevent wear degradation from high UV exposure. This IP20-rated LED bar has been designed for indoor use only and comes with an aluminium housing with an adjustable bracket for versatile mounting options. The Antari DarkFX Drive 4 or Drive 4 MKII fixture driver (sold separately) is required for power and DMX control.

PRO UV LED bar with 12 x 1.9 W UV LED, deep UV wavelength (365 nM)

• High-efficiency UV LED
• Peak wavelength at 365 nm
• Minimum visible light
• High output at full intensity
• Special optics will not degrade due to high UV exposure
• Power supply and DMX control via optional Antari DarkFX Drive 4 MK2 fixture driver
• Bare cable ends
• LED: 12 x high-power 1,9 W ultra violet (UV)
• The device is cooled by passive convection
• Controlling by system controller (not included)
• Effect: UV effect
• Power supply: 48 V DC 500 mA
• Power consumption: 24 W
• IP classification: IP20
• Lamp type: LED lamp
• LED: 12 x high-power 1,9 W ultra violet (UV)
• Cooling: Passive convection
• Control: System controller (not included)
• Beam angle: 40°
• Beam angle (1/2 peak): 40°
• Wavelength: 365 nm
• Housing color: Black
• Dimensions: Width: 3 cm
• Depth: 1,1932 m
• Height: 10 cm
• Weight: 2,24 kg
• Legal specifications
• Special product: Not designed for household room illumination
• Intended use: Show effect lighting
