Chauvet Professional Ovation F-145WW Fresnel Warm White 70W Motorised Zoom 16-65°

Description:

Ovation E-2 FC is a compact LED ellipsoidal spotlight that delivers high quality of light and convenient features in a quiet durable design optimized for smaller venues. Its advanced full spectrum Ovation RGBA-Lime color mixing system produces exceptionally high CRI output that can be smoothly sized with an integrated manual Zoom and focusing made easier with a dedicated Focus Mode button.

Features:

Full-spectrum LED ERS-style lighting fixture for small theaters and studios
Integrated 25-50deg Zoom lens
Color temperature presets from 2800 K to 8000 K with high CRI and CQS
+/- Green adjustment and emulated red-shift via DMX or on-board control
Dedicated focus mode button for one-touch activation for focusing without a board-op.
USB port for fixture software updates

Specifications:

OPTICAL
Light Source: 1 LED (WW) 70 W, (3.6 A), 50,000 hours life expectancy
Color Temperature (at full): 3096 K
CRI: 97
Beam Angle: 16° to 48°
Field Angle: 25° to 65°
Zoom Angle: 25° to 65°
Lumens (25°): 2,787
Lumens (65°): 4,266
Illuminance (25°): 1,290 lux @ 5 m
Illuminance (65°): 252 lux @ 5 m
Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz
DYNAMIC EFFECTS
Dimmer: Electronic
Shutter/Strobe: Electronic
Zoom: Motorized
Strobe Rate: 0 to 30 Hz
Dim Modes: 4
CONNECTIONS
Power Connection: Edison (Local) plug to Neutrik powerCON
Power Input: Neutrik powerCON
Power Output: Neutrik powerCON
Data Connectors: 3- and 5-pin XLR
Cable Length (power): 5 ft (1.5 m)
CONTROL
Protocol(s): DMX, RDM
DMX Channels: 1, 2, 2 or 5
Modes/Personalities: 4 personalities (1, 2, 2, 5)
ELECTRICAL
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking: 19 units @ 120 V; 34 units @ 208 V; 38 units @ 230 V
Power and Current: 84 W, 0.70 A @ 120 V, 60 Hz
Power and Current: 81 W, 0.40 A @ 208 V, 60 Hz
Power and Current: 81 W, 0.36 A @ 230 V, 50 Hz
CERTIFICATIONS / QUALIFICATIONS
CE, MET
IP Rating: IP20, dry location
Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)
PHYSICAL
Height: 297mm
Width: 285mm
Depth: 382mm
Weight: 5kg
